1.Rated insulation voltage:660V Max;
2.Rated operating voltage:AC 600V DC600V;
3.Appointed thermal current 1th:10A;
4.Max.operating frequency:12000ps/h;
5.Loading elements 40%;
6.VO1tage operating range:80-110% rated coil vo1tage Us
7.Rated controlling capacity and rated current of the relay a s in Table 1;
8.Electrical endurance:underA.C.15 D.C.13 will be 10o;
9.Mechanical endurance:1.5×106
10.Rated coil volta Us:24,36,48,110,127,380V(50Hz);DC.24,110,220,440V;
11.Rated coil power-loss:<68VA(when clsing),<10VA(after closing)
12.The combiation form of contacts as table 2 AC-15
|
Rated controling capacity
|
Rated operating
|
|||
|
360
|
127V
|
220V
|
380V
|
660V
|
|
2.8
|
1.6
|
1
|
0.55
|
|
|
Rated controling capacity
|
Rated operating
|
||
|
360
|
110V
|
220V
|
660V
|
|
0.32
|
0.16
|
0.55
|
|
