b Auxiliary Circuit
(a)There are one pair of NO/ and /NC contact with eleciricinsuation.
(b)Rated insulation Voltage 500V.
(c)rated frequency 50-60Hz
(d)Use group,rated working voltage,appiont thermal current and rated current.
SPECIFICATIONS
|
Type
|
Rated working current of thermal relay
|
Thermal component
|
||
|
Rated current (A)
|
Rated or scale of rated current(A)
|
|||
|
JR28-LR2-D13
|
25
|
JR28-LR2-D1301
|
0.16
|
0.10-0.16
|
|
1302
|
0.25
|
0.16-0.25
|
||
|
1303
|
0.40
|
0.25-0.40
|
||
|
1304
|
0.63
|
0.40-0.63
|
||
|
1305
|
1.0
|
0.63-1.0
|
||
|
1306
|
1.6
|
1.0-1.6
|
||
|
13X6
|
2.0
|
1.25-2.0
|
||
|
1307
|
2.5
|
1.6-2.5
|
||
|
1308
|
4.0
|
2.5-4.0
|
||
|
1310
|
6.0
|
4.0-6.0
|
||
|
1312
|
8.0
|
5.5-8.0
|
||
|
1314
|
10.0
|
7.0-10.0
|
||
|
1316
|
13.0
|
9.0-13.0
|
||
|
1321
|
18.0
|
12.0-18.0
|
||
|
1322
|
25.0
|
17.0-25.0
|
||
|
JR28-LR2-D23
|
36
|
JR28-LR2-D2353
|
32
|
23.0-32.0
|
|
2355
|
36
|
28.0-36.0
|
||
|
JR28-LR2-D33
|
93
|
JR28-LR2-D3353
|
32
|
23.0-32.0
|
|
3355
|
40
|
30.0-40.0
|
||
|
3357
|
50
|
37.0-50.0
|
||
|
3359
|
65
|
48.0-65.0
|
||
|
3361
|
70
|
55.0-70.0
|
||
|
3363
|
80
|
63.080.0
|
||
|
3365
|
93
|
80.0-93.0
|
||
|
JR28-LR2--D43
|
120
|
JR28-LR2--D4365
|
104
|
83.0-104.0
|
|
4367
|
120
|
95.0-120.0
|
||
|
4369
|
140
|
110.0-140.0
|
||
